The only difference between the lighted self-locking key switch and the ordinary self-locking key switch is that the lighted switch makes full use of the space in its key to place a small light bulb or LED, one end of which is connected to the zero line, and the other end is generally connected through a Only the step-down resistor is connected in parallel with the normally open contact of the switch. When the switch is closed, the device operates and also provides power for the indicator light. Its types include diagonal simultaneous switches, parallel simultaneous switches, and spanning simultaneous switches.
In fact, with self-locking button switches and tact switches describe switch performance from different aspects; "self-locking" means that the switch can pass the locking mechanism To maintain a certain state (on or off), "tap" is the force used to operate the switch. Generally speaking, mechanical switches may be distinguished as follows:
The switch is divided into knob type, plate type (including button switch, boat switch) and button type in terms of operation mode; most of the knob type and plate type switch can be kept (locked) in the on or off state after operation. , such as the daily use of light switches, fan speed control switches, most of these switches do not need to emphasize whether they have self-locking, because there is an obvious "operation direction"; only button switches, which are pressed when used, most The button switch is used to connect or disconnect the circuit when it is pressed, and the state is restored after the release, so it is sometimes called "bell switch". Like ordinary switches, a self-locking device is added. Using the self-locking performance, it can also keep on or off by itself. This is a switch with self-locking. For certain needs, several switches are working. Only one of them is allowed to be connected, and when the rest must be disconnected, several push-button switches are combined side by side, and an "interlocking mechanism" is used to allow only one of the switches to be connected and locked, and when the other switch is pressed , the switch is locked, but at the same time the original locked switch is released (such as the "play, fast forward, fast reverse" mechanical buttons on a tape recorder). These switches can have one or more sets of contacts; there are also various locking mechanisms, among which the most widely used is to use a spring hook to slide along a heart-shaped groove, and the two tips of the heart-shaped groove correspond to the lock and release positions of the switch.
The switches on rice cookers and electric kettles are locked after being pressed, but when heated to a specified condition, the magnets or bimetals that lock the button switch state action to reset the switch and cut off the power supply at the same time (the rice cooker is switched to the heat preservation state), which may not meet the requirements of "reset after power failure".
Reset after power failure, that is, the work of the locking mechanism should be related to the power supply, and the finished product does not seem to have it, because this requirement can be achieved by using a circuit composed of a general button switch and a relay; but if only one relay (or contactor) is used, one of the A group of normally open contacts is used to control the power supply of the working coil of the relay (contactor), and the relay weighing iron is used as a switch button. After pressing the weighing iron, the contacts of the relay control coil are closed, the coil is energized, and the relay remains closed ( Self-locking), the rest of the contacts control other circuits; once the power supply is cut off, the relay is cut off immediately, the weighing iron is reset, and the equivalent button is reset. It is necessary to press the relay weighing iron again to turn on the power again. The relay is now quite a push button switch with an energized lock.
